Web Real-Time Communication in the browser – WebRTC tutorial

How many of your friends are still using Skype or any kind of native software to have a video chat? In the era of Google Hangouts, Meet or Discord you don’t need any other application than the browser of your choice. The reason is that our browsers became powerful platforms that can, besides of showing formatted texts, render graphics, access your devices and stream data using complex network protocols. Today it’s better to provide a single native platform, than many specialised applications for different needs.

WebRTC – in detail

WebRTC architecture – https://webrtc.org/architecture/

Let’s build the simple chat application

Prerequisites

Some parts of WebRTC API are incompatible between different browsers. To provide a generic solution we can use a polyfill package called adapter.

For simplification, in our examples we will use a small index.html file with a few video elements in the body:

<video playsinline autoplay></video>

and adapter script dependency:

<script src=”https://webrtc.github.io/adapter/adapter-latest.js”></script>

You can also use the package from npm or bower repository to build your source package with webpack or other module bundler.

Javascript calls can be triggered from browser’s console (hit F12) or your .js source file.

Accessing peripherals (ex.1)

First of all, we need access to the peripherals – microphone, speaker and camera. To achieve this, we can use MediaDevices.getUserMedia() function. It returns a Promise that resolves to a MediaStream object, that includes audio and video tracks. This action requires user permission to access the devices. getUserMedia() takes constraints object specifying the media types requested – we can choose audio, video or both.

const video = document.querySelector('video');
navigator.mediaDevices.getUserMedia({audio: true, video: true}).then(stream => video.srcObject = stream).catch(err => console.log(err));

Hello! With this two lines, you should be able to see yourself in the browser window.

It’s also possible to configure audio/video tracks, by passing configuration properties instead of boolean values in the constraints object.

Full example can be found here in the online editor.

Streaming data (ex.2)

Having access to media devices is crucial for audio/video communication. Now, it’s the time to “send” data between the browsers. In this tutorial, we won’t send anything through the network – for the needs of testing the communication will be placed on the same machine.

WebRTC API provides RTCPeerConnection interface that stands for connection between local and remote computer.

In this example we’ll use two video elements – for remote and local peers. As both elements are displayed on the same page, we don’t have to use signaling server to negotiate the session.

Get MediaStream from devices

Firstly, we need to access media devices (just like in the previous example):

navigator.mediaDevices.getUserMedia({ audio: true, video: true })
.then(stream => {
local.srcObject = stream;
localStream = stream;
})
.catch(err => console.log(err));

The only difference is that we are storing MediaStream object in a local variable.

Establish peer connection

Our call() function – used for establishing connection between the peers – is a bit elaborated, so let’s take a step-by-step analysis.

pc1 and pc2 variables stand for our local and remote RTCPeerConnection objects.

• 1. 1. Create RTCPeerConnection objects (should be called on both sides – remote and local).

        const pc1 = new RTCPeerConnection();
        pc1.onicecandidate = e => pc2.addIceCandidate(e.candidate);


        const pc2 = new RTCPeerConnection();
        pc2.onicecandidate = e => pc1.addIceCandidate(e.candidate);


        In a real world, setting ICE candidate should be handled by signalling server. This is our first “Hey! I’m here”. Normally it’s not possible to set candidate on the other side peer just like that, as it should be send by network. However we can make some shortcuts to keep this example clear.

     2. Set remote peer ontrack callback.

        pc2.ontrack = e => {
        remote.srcObject = e.streams[0];
        };


        When the remote peer adds a track, this callback function is executed. So that, we can set our video element to display the MediaStream – notice that they may be more than one stream in the event.

     3. Add local tracks to send them over peer connection.

        localStream.getTracks().forEach(track => pc1.addTrack(track, localStream));



        With this line we’re adding our local stream tracks (audio and video) to the list of tracks being sent over the network.

     4. Create offer – start the magic.With createOffer API method, we can get Session Description Protocol object with all of necessary information about the real-time communication that’s going to be invoked. It takes RTCOfferOptions object, that can be used to adjust the offer.

        pc1.createOffer().then(description => {
        pc1.setLocalDescription(description);
        pc2.setRemoteDescription(description);
        pc2.createAnswer().then(description => {
        pc2.setLocalDescription(description);
        pc1.setRemoteDescription(description);
        })
        })


  As a result of this method, we’ll get the Promise that resolves to SDP object that has to be properly assigned on both local and remote sides. For pc2 description object resolved with createOffer contains remote peer connection details. Finally, to make the communication work, remote peer has to answer with it’s own SDP description – again, description object should be properly assigned on both of the sides.

  It works! Data stream from our local device is being sent over WebRTC and received properly in our simulated remote peer.
  You may find full example here.

•

•
  WebRTC Tutorial – What’s next?

  This tutorial was meant to show you basic usages and concepts around Web Real-Time Communication. We’ve built a simple app that uses whole set of protocols and native browser modules to send audio/video stream over from one peer to another.


  Next step would be making this work between browser pages (e.g. with a use of localStorage to simulate socket connection) or even two machines. We could write our own signaling server, to make such basic connection work with session negotiation over the network. For production usage, it’s mostly recommended to use one of dedicated media servers that acts as Multipoint Conferencing Unit (MCU). With this we can built multi-endpoint connection (like group video chat) or mix audio and video streams from multiple sources. One of such media servers is Kurento, which provides advanced tools for building rich real-time audio/video communications over the network.

  So, everyone – go ahead and do it yourself!

  Tomasz Niedziela – Brach
